Two-Hammer Rock Driller Vertical and Horizontal

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1472664

• Place of Origin:

  China
• Two-Hammer Rock Driller for Vertical and Horizontal Drilling (Heavy Type) CZH-24-2B
  The type of Multifunctional driller is mainly used in quarrying, available for horizontal, vertical, and slantwise drilling with accuracy to divide large blocks into smaller pieces, which is necessary to assist diamond wire saw machine working in stone quarries.
  Driller CodeCZH-24-2B
  Hammer2-YT24
  rated track length2*3m
  max.drilling depth6m
  drilling diameter34mm-42mm
  minimum air pressure0.6MPa
  drilling speed60m/h(one head)
  total compressed air consumption10m3/min
  track travel2m
  Feed SystemPneumatic motor, chain
  cross travel deviceHandwheel, gear, rack
  drilling directionAny direction
  number of the hammer2
  total weight1000kg

  Brand Name:HUADA
  Price Terms:FOB Xiamen
  Payment Term:T/T, 100 T/T in advance
  Packing Info:Wooden Case
  Delivery Time:according to inquiry
  Minimum Order:1 setSupply
  Ability:50 sets
  Certificate: CE and ISO9001
