Four-hammer Rock Driller (Heavy Type) CZ-24-4B

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1435352

• Place of Origin:

  China
• Four-hammer Rock Driller (Heavy Type) CZ-24-4B
  The type of Multifunctional driller is mainly used in quarrying, available for horizontal, vertical, and slantwise drilling with accuracy to divide large blocks into smaller pieces, which is necessary to assist diamond wire saw machine working in stone quarries.
  Driller CodeCZ-24-4B
  HammerYT24/28/29
  rated track length2*3m
  max.drilling depth6m
  drilling diameter34mm-42mm
  minimum air pressure0.5-0.7MPa
  drilling speed40m/h(one head)
  total compressed air consumption20m3/min
  track travel2m
  Feed SystemPneumatic motor, chain
  cross travel deviceHandwheel,gear,rack
  drilling directionAny direction
  number of the hammer4
  total weight1100(kg)

  Brand Name:HUADA
  Price Terms:FOB Xiamen
  Payment Term:T/T, 100 T/T in advance
  Packing Info:Wooden Case
  Delivery Time:according to inquiry
  Minimum Order:1 setSupply
  Ability:50 sets
  Certificate: CE and ISO9001
